Listed as a JC65, but the specification sheet supplied with this unit is for the SK400 compact skid loader, so those are the numbers below. Call before you order if the model designation matters for your paperwork or your finance.
What it is: a small four-wheel-drive skid loader, 1,400 kg, rated to lift 400 kg with a 0.2 m³ bucket. Overall width is 930 mm, the same as the bucket, and it stands 1,729 mm tall. That combination is the whole point of the machine. It goes through a standard gate, down a side passage and into a back garden, which no full-size skid steer will do.
Power is a diesel rated 22.8 kW (31 hp) at 2,200 rpm, driving a hydrostatic four-wheel-drive transmission through a high-torque hydraulic motor. Travel speed is 0 to 8 km/h. Fuel tank is 36 liters, system pressure 17 MPa, tires 145R12C.
Reach
Max working height 2,651 mm, pin height 2,301 mm, dump height 1,710 mm at 301 mm of dump reach. Dump angle is 41 degrees and rollback 23. Turning radius is 1,908 mm on an 800 mm wheelbase, with a 20-degree departure angle.
Be realistic about ground clearance. 141 mm is not much. On soft or rutted ground this machine bellies out sooner than a larger loader, so treat it as a hardstanding and lawn machine rather than a mud machine. Noise is quoted at 107 dB(A), so wear ear protection.
| Spec sheet model | SK400 skid steer loader |
|---|---|
| Load capacity | 400 kg |
| Weight | 1,400 kg |
| Engine | Diesel, 22.8 kW (31 hp) at 2,200 rpm |
| Drive | Hydrostatic four-wheel drive |
| Travel speed | 0 to 8 km/h |
| Bucket capacity | 0.2 m³ |
| Max working height | 2,651 mm |
| Max pin height | 2,301 mm |
| Max dump height | 1,710 mm |
| Max dump distance | 301 mm |
| Total height | 1,729 mm |
| Total width | 930 mm |
| Total length | 2,655 mm |
| Wheelbase | 800 mm |
| Ground clearance | 141 mm |
| Turning radius | 1,908 mm |
| Tires | 145R12C |
| Fuel tank | 36 l |
Flat $550 delivery, continental US. Returns within 30 days of delivery.
